Water heaters

HOT WATER BOILERS for making hot or superheated water

Up-to-date innovative biomass hot water boilers which are able to operate in any climatic conditions and feature high efficiency are used not only in industry (for example, in woodworking for heating and drying chambers), but also for the municipal purposes for cities district heating.

MODEL RANGE

BOILERS SPECIFICATIONS

#

Series of boilers for dry fuel with humidity from 5 to 35%

Boiler capacity 0.3 to 2 MW
Purpose of the boiler water heating
Boiler type flue-tube, three-way
Mounting position horizontal
efficiency up to 90%
- working fluid water
operating pressure up to 6 bar
operating water temperature up to 115°C
the lowest permissible water temperature
at the boiler inlet
70°C
Type of grate chute, fixed
Type of fuel biomass
#

Series of boilers for natural humidity fuel from 35% to 50%

Boiler capacity 0.3 to 2 MW
Purpose of the boiler water heating
Boiler type flue-tube, three-way
Mounting position horizontal
efficiency 80%
- working fluid water
operating pressure up to 6 bar
operating water temperature up to 115°C
the lowest permissible water temperature
at the boiler inlet
70°C
Type of grate chute, fixed
Type of fuel biomass
#

Series of boilers for complex fuel with high ash content (peat, bark) and humidity up to 65%

Boiler capacity 0.7 to 10 MW
Purpose of the boiler water heating
Boiler type flue-tube, two-way, with
automatic cleaning
Mounting position horizontal
efficiency 85%
- working fluid water
operating pressure up to 6 bar/ 12 bar
operating water temperature up to 115°C/ 150°C
the lowest permissible water temperature
at the boiler inlet
70°C
Type of grate reciprocating
Type of fuel biomass

For efficient use of biomass, the water heating plants cover the entire temperature range from 90 to 150 °C. Depending on heat supply operating temperatures (heat networks with low or high temperature), and to increase efficiency, flue gas condensation systems may be provided.

In the production of equipment, we offer customized solutions optimal for your production process and the fuel you have.

TERMOWOOD and BIOMASSE series:

UVT.0300B UVT.0400B UVT.0500B UVT.0750B UVT.1000B UVT.1500B UVT.2000B

ENERGY series:

UVT.0750E UVT.1000E UVT.1500E UVT.2000E UVT.3000E UVT.4000E UVT.6000E UVT.5000E UVT.8000E UVT.10000E UVT.12000E UVT.16000E UVT.20000E

Series of boilers using gas and liquid fuel:

K.100HW K.150HW K.200HW K.300HW K.400HW K.500HW K.600HW K.800HW K.1000HW K.1200HW K.1600HW K.2000HW K.2500HW K.3000HW
